9660 T-2 Schäffer 9660 T-2 Specifications & Technical Data (2016—2026)

Weight: 13t – Standard tyres: 500/70-R24 AS – Tipping load: 7900kg – Wheel base: 2.9m – Travel speed: 30km/h – Steering mode: KL

9660 T-2

Years of manufacture: 2016—2026

Data sheet
Valuate & Sell
Spare parts
Transport
News

Technical specs - 9660 T-2 Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 13 t

Standard tyres: 500/70-R24 AS

Tipping load: 7900 kg

Wheel base: 2.9 m

Travel speed: 30 km/h

Steering mode: KL

Max. discharge height: 5.1 m

Turning radius outside: 4.2 m

Turning radius inside: 2.4 m

Transport length: 5.9 m

Transport width: 2.49 m

Transport height: 2.97 m

Engine manuf.: Deutz

Engine type: TCD5.2

Engine power: 130 kW

Displacement: 5.2 l

No. of cylinders: 4

Emission level: V

More technical details, like: operating weight, max. height at the shovel pivot point, overcharging height, model series, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin: Yes
telescopic: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Schäffer 9660 T-2 FAQ

When did production of the Schu0000e4ffer 9660 T-2 start?

The Schu0000e4ffer 9660 T-2 was first produced in 2016.

What is the weight of the Schu00e4ffer 9660 T-2?

The Schu00e4ffer 9660 T-2 has a weight of 13 tonnes.

What are the transport dimensions of the Schu00e4ffer 9660 T-2 yard loader?

The Schu00e4ffer 9660 T-2 has a transport length of 5.9 meters, a transport width of 2.49 meters, and a transport height of 2.97 meters.

What is the travel speed of the Schu00e4ffer 9660 T-2 yard loader?

The Schu00e4ffer 9660 T-2 yard loader has a travel speed of 30 km/h.

What are the maneuverability specifications of the Schu00e4ffer 9660 T-2 yard loader?

The Schu00e4ffer 9660 T-2 features articulated-frame steering with an outside turning radius of 4.2 meters and an inside turning radius of 2.4 meters.

What are the standard tyre specifications for the Schu00e4ffer 9660 T-2?

The Schu00e4ffer 9660 T-2 is equipped with standard tyres sized 500/70-R24 AS.

What is the wheel base of the Schu00e4ffer 9660 T-2?

The Schu00e4ffer 9660 T-2 has a wheel base of 2.9 meters.

What is the mass capacity of the Schu00e4ffer 9660 T-2 yard loader?

The Schu00e4ffer 9660 T-2 has a tipping load capacity of 7900 kilograms.

What is the maximum discharge height of the Schu00e4ffer 9660 T-2 yard loader?

The Schu00e4ffer 9660 T-2 has a maximum discharge height of 5.1 meters.

How much is a Schu00e4ffer 9660 T-2 Yard loader (2016u20132025) worth?

The residual value of the Schu00e4ffer 9660 T-2 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
