9640 T Schäffer 9640 T Specifications & Technical Data (2018—2021)
Technical specs - 9640 T Schäffer
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 8.4 t
- Standard tyres
- 460/70-24 S
- Tipping load
- 5350 kg
- Wheel base
- 2.615 m
- Travel speed
- 20 km/h
- Steering mode
- KL
- Max. discharge height
- 4.574 m
- Turning radius outside
- 3.98 m
- Turning radius inside
- 2.28 m
- Transport length
- 5.452 m
- Transport width
- 2.38 m
- Transport height
- 2.86 m
- Engine manuf.
- Deutz
- Engine type
- N/A
- Engine power
- 100 kW
- Displacement
- 3.621 l
- Revolutions at max torque
- 1600 rpm
- Max. torque
- 500 Nm
- No. of cylinders
- 4
- Emission level
- Tier 4 f
More technical details, like: operating weight, max. height at the shovel pivot point, overcharging height, model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Special equipment
- Cabin
-
Yes
- telescopic
-
Yes
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
