9630 T Schäffer 9630 T Specifications & Technical Data (2016—2018)

Weight: 8t – Standard tyres: 18-22.5 TL AS – Tipping load: 4200kg – Wheel base: 2.52m – Travel speed: 20km/h – Steering mode: KL

9630 T

Years of manufacture: 2016—2018

Data sheet
Valuate & Sell
Spare parts
Transport
News

Technical specs - 9630 T Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8 t

Standard tyres: 18-22.5 TL AS

Tipping load: 4200 kg

Wheel base: 2.52 m

Travel speed: 20 km/h

Steering mode: KL

Turning radius inside: 4.7 m

Transport length: 4.43 m

Transport width: 2.24 m

Transport height: 6.13 m

Engine manuf.: Deutz

Engine type: k.A.

Engine power: 90 kW

More technical details, like: operating weight, max. height at the shovel pivot point, overcharging height, max. discharge height, turning radius outside, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Special equipment

Cabin: Yes
telescopic: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

9630 T Schäffer Specification for Europe (DE)

Schäffer 9630 T FAQ

When was the Schu00e4ffer 9630 T manufactured?

The Schu00e4ffer 9630 T was manufactured from 2016 to 2018.

What is the weight of the Schu00e4ffer 9630 T yard loader?

The Schu00e4ffer 9630 T yard loader has a weight of 8 tonnes.

What are the physical dimensions of the Schu00e4ffer 9630 T yard loader?

The Schu00e4ffer 9630 T has a transport length of 4.43 meters, a transport width of 2.24 meters, and a transport height of 6.13 meters.

What is the travel speed of the Schu00e4ffer 9630 T?

The Schu00e4ffer 9630 T has a travel speed of 20 km/h.

What are the maneuverability specifications of the Schu00e4ffer 9630 T?

The Schu00e4ffer 9630 T features articulated-frame steering and has an inside turning radius of 4.7 meters.

What are the standard tyre specifications for the Schu00e4ffer 9630 T?

The Schu00e4ffer 9630 T is equipped with standard tyres sized 18-22.5 TL AS.

What is the wheelbase of the Schu00e4ffer 9630 T yard loader?

The Schu00e4ffer 9630 T has a wheelbase of 2.52 meters.

What is the mass capacity of the Schu00e4ffer 9630 T?

The Schu00e4ffer 9630 T has a tipping load of 4200 kilograms.

How much is a Schu00e4ffer 9630 T Yard loader (2016u20132018) worth?

The residual value of the Schu00e4ffer 9630 T depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
