8610 T Schäffer 8610 T Specifications & Technical Data (2016—2018)

Weight: 7.55t – Standard tyres: 405/70-20 AS – Tipping load: 3800kg – Wheel base: 2.48m – Travel speed: 20km/h – Steering mode: KL

8610 T

Years of manufacture: 2016—2018

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 8610 T Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.55 t

Standard tyres: 405/70-20 AS

Tipping load: 3800 kg

Wheel base: 2.48 m

Travel speed: 20 km/h

Steering mode: KL

Turning radius inside: 4.19 m

Transport length: 3.65 m

Transport width: 2.24 m

Transport height: 6.04 m

Engine manuf.: Deutz

Engine type: k.A.

Engine power: 75 kW

Revolutions at max torque: 2600 rpm

More technical details, like: operating weight, max. height at the shovel pivot point, overcharging height, max. discharge height, turning radius outside, model series, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Special equipment

Cabin: Yes
telescopic: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

8610 T Schäffer Specification for Europe (DE)

Schäffer 8610 T FAQ

When was the Schu00e4ffer 8610 T manufactured?

The Schu00e4ffer 8610 T was manufactured from 2016 to 2018.

What is the weight of the Schu00e4ffer 8610 T yard loader?

The Schu00e4ffer 8610 T yard loader has a weight of 7.55 tonnes.

What are the transport dimensions of the Schu00e4ffer 8610 T yard loader?

The Schu00e4ffer 8610 T has a transport length of 3.65 meters, a transport width of 2.24 meters, and a transport height of 6.04 meters.

What is the travel speed of the Schu00e4ffer 8610 T yard loader?

The Schu00e4ffer 8610 T yard loader has a travel speed of 20 km/h.

What are the maneuverability specifications of the Schu00e4ffer 8610 T yard loader?

The Schu00e4ffer 8610 T features articulated-frame steering and has an inside turning radius of 4.19 meters.

What are the tyre specifications for the Schu00e4ffer 8610 T?

The Schu00e4ffer 8610 T is equipped with standard tyres sized 405/70-20 AS.

What are the chassis specifications of the Schu00e4ffer 8610 T?

The Schu00e4ffer 8610 T has a wheel base of 2.48 meters.

What is the tipping load capacity of the Schu00e4ffer 8610 T yard loader?

The Schu00e4ffer 8610 T yard loader has a tipping load capacity of 3800 kilograms.

How much is a Schu00e4ffer 8610 T Yard loader (2016u20132018) worth?

The residual value of the Schu00e4ffer 8610 T depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
