4350 Z Schäffer 4350 Z Specifications & Technical Data (2016—2018)

Weight: 3.4t – Standard tyres: 11.5/80-15.3 AS – Tipping load: 2149kg – Wheel base: 2m – Travel speed: 20km/h – Steering mode: KL

4350 Z

Years of manufacture: 2016—2018

Data sheet
Valuate & Sell
Spare parts
Transport
News

Technical specs - 4350 Z Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.4 t

Standard tyres: 11.5/80-15.3 AS

Tipping load: 2149 kg

Wheel base: 2 m

Travel speed: 20 km/h

Steering mode: KL

Max. discharge height: 2.5 m

Turning radius outside: 3.01 m

Turning radius inside: 1.45 m

Transport length: 4.05 m

Transport width: 1.71 m

Transport height: 2.27 m

Engine manuf.: Kubota

Engine type: k.A.

Engine power: 37 kW

No. of cylinders: 4

More technical details, like: operating weight, max. height at the shovel pivot point, overcharging height, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Special equipment

Cabin: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

4350 Z Schäffer Specification for Europe (DE)

Schäffer 4350 Z FAQ

When was the Schu00e4ffer 4350 Z manufactured?

The Schu00e4ffer 4350 Z was manufactured from 2016 to 2018.

What is the weight of the Schu00e4ffer 4350 Z?

The Schu00e4ffer 4350 Z has a weight of 3.4 tonnes.

What are the transport dimensions of the Schu00e4ffer 4350 Z?

The Schu00e4ffer 4350 Z has a transport length of 4.05 meters, a transport width of 1.71 meters, and a transport height of 2.27 meters.

What is the travel speed of the Schu00e4ffer 4350 Z yard loader?

The Schu00e4ffer 4350 Z yard loader has a travel speed of 20 km/h.

What are the maneuverability specifications of the Schu00e4ffer 4350 Z yard loader?

The Schu00e4ffer 4350 Z features articulated-frame steering with an outside turning radius of 3.01 meters and an inside turning radius of 1.45 meters.

What are the standard tyre specifications for the Schu00e4ffer 4350 Z?

The Schu00e4ffer 4350 Z comes equipped with standard tyres sized 11.5/80-15.3 AS.

What is the wheel base of the Schu00e4ffer 4350 Z yard loader?

The Schu00e4ffer 4350 Z yard loader has a wheel base of 2 meters.

What is the tipping load capacity of the Schu00e4ffer 4350 Z yard loader?

The Schu00e4ffer 4350 Z has a tipping load capacity of 2149 kilograms.

What is the maximum discharge height of the Schu00e4ffer 4350 Z yard loader?

The Schu00e4ffer 4350 Z has a maximum discharge height of 2.5 meters.

How much is a Schu00e4ffer 4350 Z Yard loader (2016u20132018) worth?

The residual value of the Schu00e4ffer 4350 Z depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
