3650 T Schäffer 3650 T Specifications & Technical Data (2021—2026)

Weight: 3.8t – Standard tyres: 15.0/55-17 AS – Tipping load: 1580kg – Wheel base: 1.8m – Travel speed: 20km/h – Steering mode: KL

3650 T

Years of manufacture: 2021—2026

Data sheet
Valuate & Sell
Spare parts
Transport
News

Technical specs - 3650 T Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.8 t

Standard tyres: 15.0/55-17 AS

Tipping load: 1580 kg

Wheel base: 1.8 m

Travel speed: 20 km/h

Steering mode: KL

Max. discharge height: 2.14 m

Turning radius outside: 2.33 m

Turning radius inside: 1.23 m

Transport length: 3.485 m

Transport width: 1.57 m

Transport height: 2.15 m

Engine manuf.: Kubota

Engine type: D1803-CR

Engine power: 28 kW

No. of cylinders: 3

Emission level: V

More technical details, like: operating weight, max. height at the shovel pivot point, overcharging height, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin: Yes
telescopic: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Schäffer 3650 T FAQ

When did production of the Schu00e4ffer 3650 T start?

The Schu00e4ffer 3650 T was first produced in 2021.

What is the weight of the Schu00e4ffer 3650 T yard loader?

The Schu00e4ffer 3650 T yard loader weighs 3.8 tonnes.

What are the physical dimensions of the Schu00e4ffer 3650 T yard loader?

The Schu00e4ffer 3650 T has a transport length of 3.49 meters, a transport width of 1.57 meters, and a transport height of 2.15 meters.

What is the travel speed of the Schu00e4ffer 3650 T yard loader?

The Schu00e4ffer 3650 T yard loader has a travel speed of 20 km/h.

What are the maneuverability specifications of the Schu00e4ffer 3650 T yard loader?

The Schu00e4ffer 3650 T features articulated-frame steering with an outside turning radius of 2.33 meters and an inside turning radius of 1.23 meters.

What are the standard tyre specifications for the Schu00e4ffer 3650 T?

The Schu00e4ffer 3650 T is equipped with standard tyres sized 15.0/55-17 AS.

What is the wheelbase of the Schu00e4ffer 3650 T?

The Schu00e4ffer 3650 T has a wheelbase of 1.8 meters.

What is the tipping load capacity of the Schu00e4ffer 3650 T yard loader?

The Schu00e4ffer 3650 T yard loader has a tipping load capacity of 1580 kilograms.

What is the maximum discharge height of the Schu00e4ffer 3650 T yard loader?

The Schu00e4ffer 3650 T yard loader has a maximum discharge height of 2.14 meters.

How much is a Schu00e4ffer 3650 T Yard loader (2021u20132025) worth?

The residual value of the Schu00e4ffer 3650 T depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
