3630 Schäffer 3630 Specifications & Technical Data (2021—2026)

Weight: 2.3t – Standard tyres: 10.0/75-15.3 AS – Tipping load: 1421kg – Wheel base: 1.745m – Travel speed: 20km/h – Steering mode: KL

Technical specs - 3630 Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.3 t
Standard tyres
10.0/75-15.3 AS
Tipping load
1421 kg
Wheel base
1.745 m
Travel speed
20 km/h
Steering mode
KL
max. height at the shovel pivot point
2.88 m
Overcharging height
2.675 m
Max. discharge height
2.09 m
Turning radius outside
2.22 m
Turning radius inside
1.02 m
Transport length
3.315 m
Transport width
1.37 m
Transport height
2.23 m
Engine manuf.
Kubota
Engine type
D1703-M-DI
Engine power
18.5 kW
Displacement
1.647 l
Revolutions at max torque
2400 rpm
No. of cylinders
3
Emission level
V

More technical details, like: operating weight, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Schäffer 3630 FAQ

When was the Schu00e4ffer 3630 manufactured?

The Schu00e4ffer 3630 was first produced in 2021.

What is the weight of the Schu00e4ffer 3630 yard loader?

The Schu00e4ffer 3630 yard loader has a weight of 2.3 tonnes.

What are the transport dimensions of the Schu00e4ffer 3630 yard loader?

The Schu00e4ffer 3630 has a transport length of 3.32 meters, a transport width of 1.37 meters, and a transport height of 2.23 meters.

What is the travel speed of the Schu00e4ffer 3630 yard loader?

The Schu00e4ffer 3630 yard loader has a travel speed of 20 km/h.

What are the maneuverability specifications of the Schu00e4ffer 3630 yard loader?

The Schu00e4ffer 3630 yard loader features articulated-frame steering with an outside turning radius of 2.22 meters and an inside turning radius of 1.02 meters.

What are the standard tyre specifications for the Schu00e4ffer 3630 yard loader?

The Schu00e4ffer 3630 yard loader is equipped with standard tyres sized 10.0/75-15.3 AS.

What is the chassis specification of the Schu00e4ffer 3630?

The Schu00e4ffer 3630 has a wheel base of 1.745 meters.

What is the mass capacity of the Schu00e4ffer 3630 yard loader?

The Schu00e4ffer 3630 yard loader has a tipping load of 1421 kilograms.

What is the maximum discharge height of the Schu00e4ffer 3630 yard loader?

The Schu00e4ffer 3630 yard loader has a maximum discharge height of 2.09 meters.

How much is a Schu00e4ffer 3630 Yard loader (2021u20132025) worth?

The residual value of the Schu00e4ffer 3630 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Schäffer 3630 overview

Dimension

Schäffer 2024: Simple, Efficient and Good Value for Money

When it comes to small spaces, these loaders excel. With an overall width of just 90.5 cm, the Schäffer 2024 will fit through almost any door. These compact dimensions mean that manual work can be mechanised in buildings that were previously inaccessible, making work faster, easier and more productive. The differences are found in the transmission systems. Thanks to their simple technology, the 2024 model offers the most affordable entry into the Schäffer world, yet you can be confident of the same high quality as all Schäffer loaders. They retain their value over years with high residual values on the second-hand market.


Hydraulic

Multi High Flow

The new Multi High Flow (MHF) hydraulic system is an option for the Schäffer 3650 and 4670 yard loaders that increases the versatility of these machines. Supplying an oil flow of up to 87l/min (3650) and 108l/min (4670), the MHF system powers attachments that require a very high oil flow to the remote couplers. Yet, there is more to Schäffer Multi High Flow! On the one hand, the system is also suitable for operating attachments that are less power sapping by reducing the oil flow; on the other hand it powers hydraulic ancillaries and the regular lift/drop functions without causing a drop in the oil flow to the main consumer. For example, Multi High Flow is able to operate a high-output straw bedder at maximum power, its hydraulic spout and the loader boom all at the same time. In these applications, the machine is making maximum use of the enormous potential delivered by MHF – all conveniently controlled from the joystick. Furthermore, the overflow oil line on these machines also serves as an additional pressure-free return. MHF is available as an option on the 3650 and 4670 models.


Drive

Motor Room Design

The motor room opens forwards. This makes all service points easily accessible from both sides of the machine. The ergonomics of this loader are exceptional. The driver has a lot of room despite the very compact dimensions of this machine, and can work comfortably thanks to the optimised position of the joystick and steering wheel.


Benefits

Very high thrust forcesNo need to manually shift down a gear when going uphillEven at high speed the maximum thrust is always available, e.g. when driving in muck heapsEnhanced driving comfort, faster working


Ergonomics at its Best

Driver comfort was our top priority when designing the cabin of the 4670. A range of features contribute to a very comfortable work environment, so the driver can feel fresh, even after long working days. All operating and control instruments are clearly laid out and user-friendly, and easily accessed from the comfortable seat with impressive legroom. The generous use of glass delivers perfect visibility for working and manoeuvring. The third control circuit is integrated in the joystick, with no need to change the handle to operate the additional control circuit.


Axle

Bonnet Maintenance

The front and rear bonnet of the 2028 SLT are easy to open, making maintenance to carry out.
