Technical specs - 3550 T Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.7 t

Standard tyres: 15.0/55-17 AS

Tipping load: 1710 kg

Wheel base: 1.92 m

Travel speed: 20 km/h

Steering mode: KL

Max. discharge height: 3.15 m

Turning radius outside: 2.97 m

Transport length: 4.07 m

Transport width: 1.71 m

Transport height: 2.27 m

Engine manuf.: Kubota

Engine type: k.A.

Engine power: 37 kW

No. of cylinders: 4

More technical details, like: operating weight, max. height at the shovel pivot point, overcharging height, turning radius inside, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Special equipment

Cabin: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

3550 T Schäffer Specification for Europe (DE)

Schäffer 3550 T FAQ

When was the Schu00e4ffer 3550 T manufactured?

The Schu00e4ffer 3550 T was manufactured from 2016 to 2018.

What is the weight of the Schu00e4ffer 3550 T yard loader?

The Schu00e4ffer 3550 T yard loader has a weight of 3.7 tonnes.

What are the transport dimensions of the Schu00e4ffer 3550 T yard loader?

The Schu00e4ffer 3550 T has a transport length of 4.07 meters, a transport width of 1.71 meters, and a transport height of 2.27 meters.

What is the travel speed of the Schu00e4ffer 3550 T yard loader?

The Schu00e4ffer 3550 T yard loader has a travel speed of 20 km/h.

What are the maneuverability specifications of the Schu00e4ffer 3550 T yard loader?

The Schu00e4ffer 3550 T features articulated-frame steering and has an outside turning radius of 2.97 meters.

What are the standard tyre specifications for the Schu00e4ffer 3550 T?

The Schu00e4ffer 3550 T is equipped with standard tyres sized 15.0/55-17 AS.

What is the wheelbase of the Schu00e4ffer 3550 T yard loader?

The Schu00e4ffer 3550 T has a wheelbase of 1.92 meters.

What is the tipping load capacity of the Schu00e4ffer 3550 T?

The Schu00e4ffer 3550 T has a tipping load capacity of 1710 kilograms.

What is the maximum discharge height of the Schu00e4ffer 3550 T yard loader?

The Schu00e4ffer 3550 T yard loader has a maximum discharge height of 3.15 meters.

How much is a Schu00e4ffer 3550 T Yard loader (2016u20132018) worth?

The residual value of the Schu00e4ffer 3550 T depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
