2336 SLT Schäffer 2336 SLT Specifications & Technical Data (2016—2018)

Weight: 2.35t – Standard tyres: 10.0/75-15.3 AS – Tipping load: 1321kg – Wheel base: 1.65m – Travel speed: 15km/h – Steering mode: KL

2336 SLT

Years of manufacture: 2016—2018

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 2336 SLT Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.35 t

Standard tyres: 10.0/75-15.3 AS

Tipping load: 1321 kg

Wheel base: 1.65 m

Travel speed: 15 km/h

Steering mode: KL

Max. discharge height: 2.045 m

Turning radius outside: 2.32 m

Transport length: 3.23 m

Transport width: 1.57 m

Transport height: 1.95 m

Engine manuf.: Kubota

Engine type: k.A.

Engine power: 26 kW

Revolutions at max torque: 2800 rpm

No. of cylinders: 3

More technical details, like: operating weight, max. height at the shovel pivot point, overcharging height, turning radius inside, model series, dimension lxwxh, displacement, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Special equipment

Cabin: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Schäffer 2336 SLT FAQ

When was the Schu00e4ffer 2336 SLT manufactured?

The Schu00e4ffer 2336 SLT was manufactured from 2016 to 2018.

What is the weight of the Schu00e4ffer 2336 SLT yard loader?

The Schu00e4ffer 2336 SLT yard loader has a weight of 2.35 tonnes.

What are the transport dimensions of the Schu00e4ffer 2336 SLT yard loader?

The Schu00e4ffer 2336 SLT has a transport length of 3.23 meters, a transport width of 1.57 meters, and a transport height of 1.95 meters.

What is the travel speed of the Schu00e4ffer 2336 SLT yard loader?

The Schu00e4ffer 2336 SLT yard loader has a travel speed of 15 km/h.

What are the maneuverability specifications of the Schu00e4ffer 2336 SLT?

The Schu00e4ffer 2336 SLT features articulated-frame steering and has an outside turning radius of 2.32 meters.

What are the standard tyre specifications for the Schu00e4ffer 2336 SLT?

The Schu00e4ffer 2336 SLT is equipped with standard tyres sized 10.0/75-15.3 AS.

What is the wheel base of the Schu00e4ffer 2336 SLT?

The Schu00e4ffer 2336 SLT has a wheel base of 1.65 meters.

What is the tipping load capacity of the Schu00e4ffer 2336 SLT?

The Schu00e4ffer 2336 SLT has a tipping load capacity of 1321 kilograms.

What is the maximum discharge height of the Schu00e4ffer 2336 SLT yard loader?

The Schu00e4ffer 2336 SLT has a maximum discharge height of 2.05 meters.

How much is a Schu00e4ffer 2336 SLT Yard loader (2016u20132018) worth?

The residual value of the Schu00e4ffer 2336 SLT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
