2030 Schäffer 2030 Specifications & Technical Data (2016—2018)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Technical specs - 2030 Schäffer
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 1.8 t
- Standard tyres
- 7.00-12 AS
- Tipping load
- 1500 kg
- Wheel base
- 1.375 m
- Travel speed
- 15 km/h
- Steering mode
- KL
- Max. discharge height
- 1.965 m
- Turning radius outside
- 1.95 m
- Transport length
- 1.95 m
- Transport width
- 0.66 m
- Transport height
- 3.53 m
- Engine manuf.
- Kubota
- Engine type
- k.A.
- Engine power
- 22 kW
- No. of cylinders
- 3
More technical details, like: operating weight, max. height at the shovel pivot point, overcharging height, turning radius inside, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.
Special equipment
- Cabin
-
No
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
