2024 Schäffer 2024 Specifications & Technical Data (2016—2021)
Technical specs - 2024 Schäffer
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 1.7 t
- Standard tyres
- 7.00-12 AS
- Tipping load
- 786 kg
- Wheel base
- 1.375 m
- Travel speed
- 12 km/h
- Steering mode
- KL
- Max. discharge height
- 1.965 m
- Turning radius outside
- 1.56 m
- Turning radius inside
- 0.66 m
- Transport length
- 2.78 m
- Transport width
- 1.25 m
- Transport height
- 2.09 m
- Engine manuf.
- Kubota
- Engine type
- D1703-M-DI
- Engine power
- 18.5 kW
- Displacement
- 1.647 l
- Revolutions at max torque
- 2200 rpm
- No. of cylinders
- 3
- Emission level
- Tier 4b
More technical details, like: operating weight, max. height at the shovel pivot point, overcharging height, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.
Special equipment
- Cabin
-
No
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
Download datasheets (PDF)
