Technical specs - 1622 Schäffer
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 1.25 t
- Standard tyres
- 23x8.5-12 AS
- Tipping load
- 800 kg
- Wheel base
- 0.89 m
- Travel speed
- 16 km/h
- Steering mode
- KL
- max. height at the shovel pivot point
- 2.23 m
- Overcharging height
- 2.02 m
- Max. discharge height
- 1.51 m
- Turning radius outside
- 1.875 m
- Turning radius inside
- 0.97 m
- Transport length
- 3.05 m
- Transport width
- 1.06 m
- Transport height
- 1.99 m
- Engine manuf.
- Kubota
- Engine type
- D902
- Engine power
- 16.2 kW
- Displacement
- 0.898 l
- No. of cylinders
- 3
- Emission level
- V
More technical details, like: operating weight, model series, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.
Special equipment
- Cabin
-
No
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
