KL43.8L Kramer KL43.8L Specifications & Technical Data (2019—2026)

operating weight: 6.05t – Standard tyres: 405/70-24 – Tipping load: 4250kg – Wheel base: 2.15m – Travel speed: 20km/h – Steering mode: A

KL43.8L

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - KL43.8L Kramer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

operating weight: 6.05 t

Standard tyres: 405/70-24

Tipping load: 4250 kg

Wheel base: 2.15 m

Travel speed: 20 km/h

Steering mode: A

max. height at the shovel pivot point: 3.64 m

Overcharging height: 3.48 m

Max. discharge height: 3 m

Turning radius outside: 3 m

Transport length: 5.8 m

Transport width: 1.97 m

Transport height: 2.69 m

Engine manuf.: Deutz

Engine type: TCD2.9

Engine power: 55.4 kW

Displacement: 2.924 l

Max. torque: 300/1600 Nm

Emission level: V

More technical details, like: weight, turning radius inside, model series, dimension lxwxh, revolutions at max torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin: Yes
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Kramer KL43.8L FAQ

When was the Kramer KL43.8L manufactured?

The Kramer KL43.8L was first produced in 2019.

What is the operating weight of the Kramer KL43.8L?

The Kramer KL43.8L has an operating weight of 6.05 tonnes.

What are the transport dimensions of the Kramer KL43.8L yard loader?

The Kramer KL43.8L has a transport length of 5.8 meters, a transport width of 1.97 meters, and a transport height of 2.69 meters.

What is the travel speed of the Kramer KL43.8L yard loader?

The Kramer KL43.8L yard loader has a travel speed of 20 km/h.

What are the maneuverability specifications of the Kramer KL43.8L?

The Kramer KL43.8L features all-wheel steering and has an outside turning radius of 3 meters.

What are the standard tyre specifications for the Kramer KL43.8L?

The Kramer KL43.8L is equipped with standard tyres sized 405/70-24.

What is the wheelbase of the Kramer KL43.8L?

The Kramer KL43.8L has a wheelbase of 2.15 meters.

What is the mass capacity of the Kramer KL43.8L yard loader?

The Kramer KL43.8L has a tipping load of 4250 kilograms.

What are the key height and reach specifications of the Kramer KL43.8L yard loader?

The Kramer KL43.8L has an overcharging height of 3.48 meters, a maximum discharge height of 3 meters, and a maximum height at the shovel pivot point of 3.64 meters.

How much is a Kramer KL43.8L Yard loader (2019u20132025) worth?

The residual value of the Kramer KL43.8L depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Buy & Rent

Compare Kramer KL43.8L with similar Yard loader

Kramer KL43.8L

operating weight:: 6.05 t

Standard tyres:: 405/70-24

Tipping load:: 4250 kg

Wheel base:: 2.15 m

Kramer KL10.5

operating weight:: 1.555 t

Standard tyres:: 28x9.00-15

Tipping load:: 1080 kg

Wheel base:: 1.525 m
