KL43.8 Kramer KL43.8 Specifications & Technical Data (2019—2026)
.png)
.png)
Visit Kramer live at
Technical specs - KL43.8 Kramer
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- operating weight
- 6.05 t
- Standard tyres
- 405/70-24
- Tipping load
- 4250 kg
- Wheel base
- 2.15 m
- Travel speed
- 20 km/h
- Steering mode
- A
- max. height at the shovel pivot point
- 3.45 m
- Overcharging height
- 3.2 m
- Max. discharge height
- 2.65 m
- Turning radius outside
- 3 m
- Transport length
- 5.8 m
- Transport width
- 1.97 m
- Transport height
- 2.69 m
- Engine manuf.
- Deutz
- Engine type
- TCD2.9
- Engine power
- 55.4 kW
- Displacement
- 2.924 l
- Max. torque
- 300/1600 Nm
- Emission level
- V
More technical details, like: weight, turning radius inside, model series, dimension lxwxh, revolutions at max torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Special equipment
- Cabin
-
Yes
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
Yes
- Quick hitch mech.
-
No
