KL33.5L Kramer KL33.5L Specifications & Technical Data (2019—2026)

operating weight: 4.29t – Standard tyres: 340/80-18 – Tipping load: 3300kg – Wheel base: 2.02m – Travel speed: 20km/h – Steering mode: A

KL33.5L

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - KL33.5L Kramer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

operating weight: 4.29 t

Standard tyres: 340/80-18

Tipping load: 3300 kg

Wheel base: 2.02 m

Travel speed: 20 km/h

Steering mode: A

max. height at the shovel pivot point: 3.25 m

Overcharging height: 3.1 m

Max. discharge height: 2.56 m

Turning radius outside: 2.84 m

Transport length: 4.64 m

Transport width: 1.74 m

Transport height: 2.45 m

Engine manuf.: Kohler

Engine type: KDI2504TCRS5

Engine power: 55.4 kW

Displacement: 2.482 l

Revolutions at max torque: 2600 rpm

Max. torque: 300/1500 Nm

No. of cylinders: 4

Emission level: V

More technical details, like: weight, turning radius inside, model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin: Yes
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Kramer KL33.5L FAQ

When did production of the Kramer KL33.5L start?

The Kramer KL33.5L was first produced in 2019.

What is the operating weight of the Kramer KL33.5L?

The Kramer KL33.5L has an operating weight of 4.29 tonnes.

What are the physical dimensions of the Kramer KL33.5L yard loader?

The Kramer KL33.5L has a transport length of 4.64 meters, a transport width of 1.74 meters, and a transport height of 2.45 meters.

What is the travel speed of the Kramer KL33.5L yard loader?

The Kramer KL33.5L yard loader has a travel speed of 20 km/h.

What are the maneuverability specifications of the Kramer KL33.5L yard loader?

The Kramer KL33.5L yard loader features all-wheel steering and has an outside turning radius of 2.84 meters.

What are the standard tyre specifications for the Kramer KL33.5L?

The Kramer KL33.5L is equipped with standard tyres sized 340/80-18.

What is the wheelbase of the Kramer KL33.5L yard loader?

The Kramer KL33.5L has a wheelbase of 2.02 meters.

What is the mass capacity of the Kramer KL33.5L yard loader?

The Kramer KL33.5L has a tipping load of 3300 kilograms.

What are the working height and reach specifications of the Kramer KL33.5L yard loader?

The Kramer KL33.5L has an overcharging height of 3.1 meters, a maximum discharge height of 2.56 meters, and a maximum height at the shovel pivot point of 3.25 meters.
