KL25.5eL Kramer KL25.5eL Specifications & Technical Data (2019—2026)

operating weight: 4.13t – Standard tyres: 12.0-18 – Tipping load: 2500kg – Wheel base: 1.85m – Travel speed: 16km/h – Steering mode: A

Yard loader Kramer KL25.5eL

Visit Kramer live at

Technical specs - KL25.5eL Kramer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

operating weight
4.13 t
Standard tyres
12.0-18
Tipping load
2500 kg
Wheel base
1.85 m
Travel speed
16 km/h
Steering mode
A
max. height at the shovel pivot point
3.3 m
Overcharging height
3.28 m
Max. discharge height
2.62 m
Turning radius outside
2.7 m
Transport length
5.14 m
Transport width
1.65 m
Transport height
2.39 m
Engine manuf.
Jungheinrich
Engine type
Elektro
Engine power
15 kW

More technical details, like: weight, turning radius inside, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Special equipment

Cabin
No
telescopic
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Kramer KL25.5eL FAQ

When did production of the Kramer KL25.5eL start?

The Kramer KL25.5eL was first produced in 2019.

What is the operating weight of the Kramer KL25.5eL?

The Kramer KL25.5eL has an operating weight of 4.13 tonnes.

What are the physical dimensions of the Kramer KL25.5eL yard loader?

The Kramer KL25.5eL has a transport length of 5.14 meters, a transport width of 1.65 meters, and a transport height of 2.39 meters.

What is the travel speed of the Kramer KL25.5eL yard loader?

The Kramer KL25.5eL yard loader has a travel speed of 16 km/h.

What are the maneuverability specifications of the Kramer KL25.5eL?

The Kramer KL25.5eL features all-wheel steering and has an outside turning radius of 2.7 meters.

What are the standard tyre specifications for the Kramer KL25.5eL?

The Kramer KL25.5eL is equipped with standard tyres sized 12.0-18.

What is the wheelbase of the Kramer KL25.5eL yard loader?

The Kramer KL25.5eL has a wheelbase of 1.85 meters.

What is the mass capacity of the Kramer KL25.5eL yard loader?

The Kramer KL25.5eL has a tipping load capacity of 2500 kilograms.

What are the working height and reach specifications of the Kramer KL25.5eL yard loader?

The Kramer KL25.5eL has an overcharging height of 3.28 meters, a maximum discharge height of 2.62 meters, and a maximum height at the shovel pivot point of 3.3 meters.

How much is a Kramer KL25.5eL Yard loader (2019u20132025) worth?

The residual value of the Kramer KL25.5eL depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
