Technical specs - KL14.5 Kramer
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- operating weight
- 2.07 t
- Standard tyres
- 27x10.5-15
- Tipping load
- 1420 kg
- Wheel base
- 1.525 m
- Travel speed
- 20 km/h
- Steering mode
- A
- max. height at the shovel pivot point
- 2.8 m
- Overcharging height
- 2.68 m
- Max. discharge height
- 2.26 m
- Turning radius outside
- 1.95 m
- Transport length
- 4.09 m
- Transport width
- 1.26 m
- Transport height
- 2.17 m
- Engine manuf.
- Yanmar
- Engine type
- 3TNV86CT
- Engine power
- 28.5 kW
- Displacement
- 1.568 l
- Revolutions at max torque
- 2600 rpm
- Max. torque
- 132.2/1690 Nm
- No. of cylinders
- 3
- Cylinder bore x stroke
- 86x90 mm
- Emission level
- V
More technical details, like: weight, turning radius inside, model series, dimension lxwxh are available in the full technical specs.
Special equipment
- Cabin
-
Yes
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
Yes
- Quick hitch mech.
-
No
Download datasheets (PDF)
Kramer KL14.5 FAQ
What is the operating weight of the Kramer KL14.5 yard loader?
What are the transport dimensions of the Kramer KL14.5 yard loader?
What is the travel speed of the Kramer KL14.5 yard loader?
What are the maneuverability specifications of the Kramer KL14.5 yard loader?
What are the standard tyre specifications for the Kramer KL14.5?
What is the wheelbase of the Kramer KL14.5 yard loader?
What is the tipping load capacity of the Kramer KL14.5?
What are the working height and reach specifications of the Kramer KL14.5 yard loader?
How much is a Kramer KL14.5 Yard loader (2020u20132025) worth?
Buy & Rent
Compare Kramer KL14.5 with similar Yard loader
.png)
Kramer KL14.5
- operating weight:
- 2.07 t
- Standard tyres:
- 27x10.5-15
- Tipping load:
- 1420 kg
- Wheel base:
- 1.525 m
Kramer KL10.5
- operating weight:
- 1.555 t
- Standard tyres:
- 28x9.00-15
- Tipping load:
- 1080 kg
- Wheel base:
- 1.525 m
