Technical specs - KL12.5 Kramer
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- operating weight
- 1.92 t
- Standard tyres
- 27x10.5-15
- Tipping load
- 1200 kg
- Wheel base
- 1.525 m
- Travel speed
- 20 km/h
- Steering mode
- A
- max. height at the shovel pivot point
- 2.8 m
- Overcharging height
- 2.68 m
- Max. discharge height
- 2.29 m
- Turning radius outside
- 1.95 m
- Transport length
- 4.05 m
- Transport width
- 1.26 m
- Transport height
- 2.17 m
- Engine manuf.
- Yanmar
- Engine type
- 3TNV82A
- Engine power
- 18.5 kW
- Displacement
- 1.331 l
- Revolutions at max torque
- 2500 rpm
- Max. torque
- 85.5/1200 Nm
- No. of cylinders
- 3
- Cylinder bore x stroke
- 82x84 mm
- Emission level
- V
More technical details, like: weight, turning radius inside, model series, dimension lxwxh are available in the full technical specs.
Special equipment
- Cabin
-
No
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
Yes
- Quick hitch mech.
-
No
Download datasheets (PDF)
Kramer KL12.5 FAQ
What is the operating weight of the Kramer KL12.5?
What are the physical dimensions of the Kramer KL12.5 yard loader?
What is the travel speed of the Kramer KL12.5 yard loader?
What are the maneuverability specifications of the Kramer KL12.5 yard loader?
What are the tyre specifications of the Kramer KL12.5 yard loader?
What is the wheelbase of the Kramer KL12.5 yard loader?
What is the mass capacity of the Kramer KL12.5?
What are the working height and reach specifications of the Kramer KL12.5 yard loader?
How much is a Kramer KL12.5 Yard loader (2020u20132025) worth?
Buy & Rent
Compare Kramer KL12.5 with similar Yard loader
.png)
Kramer KL12.5
- operating weight:
- 1.92 t
- Standard tyres:
- 27x10.5-15
- Tipping load:
- 1200 kg
- Wheel base:
- 1.525 m
Kramer KL10.5
- operating weight:
- 1.555 t
- Standard tyres:
- 28x9.00-15
- Tipping load:
- 1080 kg
- Wheel base:
- 1.525 m
