560-80 AGRI Super JCB 560-80 AGRI Super Specifications & Technical Data (2021—2026)
Visit JCB live at
.jpg){kind=logo}
Technical specs - 560-80 AGRI Super JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 11.36 t
- Standard tyres
- 500/70 R24
- Wheel base
- 2.75 m
- Travel speed
- 40 km/h
- Steering mode
- A
- Overcharging height
- 6.64 m
- Turning radius outside
- 4.1 m
- Transport length
- 5.42 m
- Transport width
- 2.55 m
- Transport height
- 2.63 m
- Model series
- 560
- Engine manuf.
- JCB
- Engine type
- DieselMax 448
- Engine power
- 97 kW
- Displacement
- 4.8 l
- Revolutions at max torque
- 2200 rpm
- Max. torque
- 550/1500 Nm
- No. of cylinders
- 4
- Emission level
- V
More technical details, like: operating weight, tipping load, max. height at the shovel pivot point, max. discharge height, turning radius inside, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Special equipment
- Cabin
-
Yes
- telescopic
-
Yes
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
