532-70 AGRI JCB 532-70 AGRI Specifications & Technical Data (2021—2026)

Weight: 7.6t – Standard tyres: 460/70 R24 – Wheel base: 2.75m – Travel speed: 40km/h – Steering mode: A – Overcharging height: 6.3m

Yard loader JCB 532-70 AGRI
Yard loader JCB 532-70 AGRI
Yard loader JCB 532-70 AGRI
Yard loader JCB 532-70 AGRI
Yard loader JCB 532-70 AGRI
Yard loader JCB 532-70 AGRI

Visit JCB live at

Technical specs - 532-70 AGRI JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.6 t
Standard tyres
460/70 R24
Wheel base
2.75 m
Travel speed
40 km/h
Steering mode
A
Overcharging height
6.3 m
Turning radius outside
3.7 m
Transport length
5.07 m
Transport width
2.34 m
Transport height
2.51 m
Model series
532
Engine manuf.
JCB
Engine type
DieselMax 448
Engine power
81 kW
Displacement
4.8 l
Revolutions at max torque
2200 rpm
Max. torque
516/1500 Nm
No. of cylinders
4
Cylinder bore x stroke
106x135 mm
Emission level
V

More technical details, like: operating weight, tipping load, max. height at the shovel pivot point, max. discharge height, turning radius inside, dimension lxwxh are available in the full technical specs.

Special equipment

Cabin
Yes
telescopic
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

JCB 532-70 AGRI FAQ

When was the JCB 532-70 AGRI produced and what is its model series?

The JCB 532-70 AGRI belongs to the 532 model series and was first produced in 2021.

What is the weight of the JCB 532-70 AGRI yard loader?

The JCB 532-70 AGRI yard loader weighs 7.6 tonnes.

What are the transport dimensions of the JCB 532-70 AGRI yard loader?

The JCB 532-70 AGRI has a transport length of 5.07 meters, a transport width of 2.34 meters, and a transport height of 2.51 meters.

What is the travel speed of the JCB 532-70 AGRI yard loader?

The JCB 532-70 AGRI yard loader has a travel speed of 40 km/h.

What are the maneuverability specifications of the JCB 532-70 AGRI?

The JCB 532-70 AGRI features all-wheel steering and has an outside turning radius of 3.7 meters.

What are the standard tyre specifications for the JCB 532-70 AGRI?

The JCB 532-70 AGRI is equipped with standard tyres sized 460/70 R24.

What is the wheelbase of the JCB 532-70 AGRI yard loader?

The JCB 532-70 AGRI yard loader has a wheelbase of 2.75 meters.

What is the overcharging height of the JCB 532-70 AGRI yard loader?

The JCB 532-70 AGRI yard loader has an overcharging height of 6.3 meters.

How much is a JCB 532-70 AGRI Yard loader (2021u20132025) worth?

The residual value of the JCB 532-70 AGRI depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
