Agri Pivot T70 Dieci Agri Pivot T70 Specifications & Technical Data (2022—2026)

Weight: 7.7t – operating weight: 8.37t – Standard tyres: 405/70x24 – Travel speed: 40km/h – Steering mode: KL – Turning radius outside: 4.58m

Agri Pivot T70

Years of manufacture: 2022—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Agri Pivot T70 Dieci

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.7 t

operating weight: 8.37 t

Standard tyres: 405/70x24

Travel speed: 40 km/h

Steering mode: KL

Turning radius outside: 4.58 m

Turning radius inside: 2.33 m

Transport length: 5.685 m

Transport width: 2.2 m

Transport height: 2.68 m

Model series: Agri Pivot

Engine manuf.: Perkins

Engine type: 904J-E36TA

Engine power: 85.9 kW

Displacement: 3.621 l

Revolutions at max torque: 2200 rpm

Max. torque: 500/1500 Nm

No. of cylinders: 4

Emission level: V

More technical details, like: tipping load, wheel base, max. height at the shovel pivot point, overcharging height, max. discharge height, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin: Yes
telescopic: Yes
Aircondition: Yes
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Dieci Agri Pivot T70 FAQ

When did production of the Dieci Agri Pivot T70 in the Agri Pivot series start?

The Dieci Agri Pivot T70, part of the Agri Pivot series, was first produced in 2022.

What are the weight specifications for the Dieci Agri Pivot T70?

The Dieci Agri Pivot T70 has a standard weight of 7.7 tonnes and an operating weight of 8.37 tonnes.

What are the transport dimensions of the Dieci Agri Pivot T70?

The Dieci Agri Pivot T70 has a transport length of 5.685 meters, a transport width of 2.2 meters, and a transport height of 2.68 meters.

What is the travel speed of the Dieci Agri Pivot T70?

The Dieci Agri Pivot T70 has a travel speed of 40 km/h.

What are the maneuverability specifications of the Dieci Agri Pivot T70?

The Dieci Agri Pivot T70 features articulated-frame steering with an outside turning radius of 4.58 meters and an inside turning radius of 2.33 meters.

What are the tyre specifications of the Dieci Agri Pivot T70?

The Dieci Agri Pivot T70 is equipped with standard tyres sized 405/70x24.

How much is a Dieci Agri Pivot T70 Yard loader (2022u20132025) worth?

The residual value of the Dieci Agri Pivot T70 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Buy & Rent

Compare Dieci Agri Pivot T70 with similar Yard loader

Dieci Agri Pivot T70

Weight:: 7.7 t

operating weight:: 8.37 t

Standard tyres:: 405/70x24

Travel speed:: 40 km/h

JCB 525-58

Weight:: 6.3 t

Standard tyres:: 15.5/80-24
