Torion 738 T Sinus Claas Torion 738 T Sinus Specifications & Technical Data (2020—2026)

Weight: 7t – Standard tyres: 405/70 R18 – Tipping load: 3800kg – Travel speed: 40km/h – Steering mode: KL – max. height at the shovel pivot point: 4.96m

Torion 738 T Sinus

Years of manufacture: 2020—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Torion 738 T Sinus Claas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7 t

Standard tyres: 405/70 R18

Tipping load: 3800 kg

Travel speed: 40 km/h

Steering mode: KL

max. height at the shovel pivot point: 4.96 m

Overcharging height: 4.5 m

Max. discharge height: 2.64 m

Turning radius outside: 4.465 m

Transport length: 5.515 m

Transport width: 2.09 m

Transport height: 2.79 m

Model series: Torion

Engine manuf.: Yanmar

Engine type: 4TNV98CT

Engine power: 54 kW

Displacement: 3.32 l

Revolutions at max torque: 2400 rpm

Max. torque: 280/1800 Nm

No. of cylinders: 4

Cylinder bore x stroke: 98x110 mm

Emission level: V

More technical details, like: operating weight, wheel base, turning radius inside, dimension lxwxh are available in the full technical specs.

Special equipment

Cabin: Yes
telescopic: Yes
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Claas Torion 738 T Sinus FAQ

When did production of the Claas Torion 738 T Sinus start?

The Claas Torion 738 T Sinus, part of the Torion model series, has been in production since 2020.

What is the weight of the Claas Torion 738 T Sinus?

The Claas Torion 738 T Sinus has a weight of 7 tonnes.

What are the transport dimensions of the Claas Torion 738 T Sinus?

The Claas Torion 738 T Sinus has a transport length of 5.52 meters, a transport width of 2.09 meters, and a transport height of 2.79 meters.

What is the travel speed of the Claas Torion 738 T Sinus?

The Claas Torion 738 T Sinus has a travel speed of 40 km/h.

What are the maneuverability specifications of the Claas Torion 738 T Sinus?

The Claas Torion 738 T Sinus features articulated-frame steering and has an outside turning radius of 4.465 meters.

What are the tyre specifications of the Claas Torion 738 T Sinus?

The Claas Torion 738 T Sinus is equipped with standard tyres sized 405/70 R18.

What is the mass capacity of the Claas Torion 738 T Sinus?

The Claas Torion 738 T Sinus has a tipping load of 3800 kilograms.

What are the working height and reach specifications of the Claas Torion 738 T Sinus?

The Claas Torion 738 T Sinus has an overcharging height of 4.5 meters, a maximum discharge height of 2.64 meters, and a maximum height at the shovel pivot point of 4.96 meters.

How much is a Claas Torion 738 T Sinus Yard loader (2020u20132025) worth?

The residual value of the Claas Torion 738 T Sinus depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
