Torion 639 Claas Torion 639 Specifications & Technical Data (2019—2026)

Weight: 5.6t – Standard tyres: 365/80 R20 – Tipping load: 3850kg – Wheel base: 2.15m – Travel speed: 20km/h – Steering mode: KL

Torion 639

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Torion 639 Claas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.6 t

Standard tyres: 365/80 R20

Tipping load: 3850 kg

Wheel base: 2.15 m

Travel speed: 20 km/h

Steering mode: KL

max. height at the shovel pivot point: 3.37 m

Overcharging height: 3 m

Max. discharge height: 3.37 m

Turning radius outside: 4.465 m

Transport length: 5.515 m

Transport width: 1.76 m

Transport height: 2.46 m

Model series: Torion

Engine manuf.: Yanmar

Engine type: 4TNV98C

Engine power: 50 kW

Displacement: 3.32 l

Revolutions at max torque: 2400 rpm

Max. torque: 235/1560 Nm

No. of cylinders: 4

Cylinder bore x stroke: 98x110 mm

Emission level: V

More technical details, like: operating weight, turning radius inside, dimension lxwxh are available in the full technical specs.

Special equipment

Cabin: Yes
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Claas Torion 639 FAQ

What is the manufacturing period or start year for the Claas Torion 639?

The Claas Torion 639, part of the Torion series, was first produced in 2019.

What is the weight of the Claas Torion 639?

The Claas Torion 639 has a weight of 5.6 tonnes.

What are the physical transport dimensions of the Claas Torion 639?

The Claas Torion 639 has a transport length of 5.52 meters, a transport width of 1.76 meters, and a transport height of 2.46 meters.

What is the travel speed of the Claas Torion 639?

The Claas Torion 639 has a travel speed of 20 km/h.

What are the maneuverability specifications of the Claas Torion 639?

The Claas Torion 639 features articulated-frame steering and has an outside turning radius of 4.465 meters.

What are the tyre specifications of the Claas Torion 639?

The Claas Torion 639 is equipped with standard tyres sized 365/80 R20.

What is the wheelbase of the Claas Torion 639?

The Claas Torion 639 has a wheelbase of 2.15 meters.

What is the mass capacity of the Claas Torion 639?

The Claas Torion 639 has a tipping load of 3850 kilograms.

What are the working height and reach specifications of the Claas Torion 639?

The Claas Torion 639 has an overcharging height of 3 meters, a maximum discharge height of 3.37 meters, and a maximum height at the shovel pivot point of 3.37 meters.

How much is a Claas Torion 639 Yard loader (2019u20132025) worth?

The residual value of the Claas Torion 639 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
