Torion 2014 Claas Torion 2014 Specifications & Technical Data (2022—2026)

Weight: 19.6t – Standard tyres: 23.5 R25 – Tipping load: 12500kg – Travel speed: 40km/h – Steering mode: KL – max. height at the shovel pivot point: 4.15m

Technical specs - Torion 2014 Claas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
19.6 t
Standard tyres
23.5 R25
Tipping load
12500 kg
Travel speed
40 km/h
Steering mode
KL
max. height at the shovel pivot point
4.15 m
Overcharging height
3.7 m
Max. discharge height
4.075 m
Turning radius outside
6.65 m
Turning radius inside
3.54 m
Transport length
8.605 m
Transport width
2.65 m
Transport height
3.37 m
Model series
Torion
Engine manuf.
Liebherr
Engine type
D 944 A7
Engine power
183 kW
Displacement
7.9 l
Revolutions at max torque
1800 rpm
Max. torque
1403/1150 Nm
No. of cylinders
4
Cylinder bore x stroke
130x150 mm
Emission level
V

More technical details, like: operating weight, wheel base, dimension lxwxh are available in the full technical specs.

Special equipment

Cabin
Yes
telescopic
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Claas Torion 2014 FAQ

When did production of the Claas Torion 2014 start?

The Claas Torion 2014 was first produced in 2022.

What is the weight of the Claas Torion 2014?

The Claas Torion 2014 has a weight of 19.6 tonnes.

What are the physical dimensions of the Claas Torion 2014 yard loader?

The Claas Torion 2014 has a transport length of 8.61 meters, a transport width of 2.65 meters, and a transport height of 3.37 meters.

What is the travel speed of the Claas Torion 2014?

The Claas Torion 2014 has a travel speed of 40 km/h.

What are the maneuverability specifications of the Claas Torion 2014 yard loader?

The Claas Torion 2014 features articulated-frame steering with an outside turning radius of 6.65 meters and an inside turning radius of 3.54 meters.

What are the tyre specifications for the Claas Torion 2014?

The Claas Torion 2014 is equipped with standard tyres of size 23.5 R25.

What is the mass capacity of the Claas Torion 2014?

The Claas Torion 2014 has a tipping load capacity of 12,500 kilograms.

What are the working height and reach specifications of the Claas Torion 2014 yard loader?

The Claas Torion 2014 has an overcharging height of 3.7 meters, a maximum discharge height of 4.08 meters, and a maximum height at the shovel pivot point of 4.15 meters.

How much is a Claas Torion 2014 Yard loader (2022u20132025) worth?

The residual value of the Claas Torion 2014 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Buy & Rent

Compare Claas Torion 2014 with similar Yard loader

Claas Torion 2014

Claas Torion 2014

Weight:
19.6 t
Standard tyres:
23.5 R25
Tipping load:
12500 kg
Travel speed:
40 km/h
Claas Torion 1812

Claas Torion 1812

Weight:
18.7 t
Standard tyres:
23.5 R25 L3
Tipping load:
12800 kg
Travel speed:
49 km/h
