Torion 1511 Claas Torion 1511 Specifications & Technical Data (2017—2020)

Weight: 14.06t – Standard tyres: 20.5 R25 – Tipping load: 7500kg – Wheel base: 2.975m – Travel speed: 40km/h – Steering mode: KL

Torion 1511

Years of manufacture: 2017—2020

Data sheet
Valuate & Sell
Spare parts
Transport
News

Technical specs - Torion 1511 Claas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 14.06 t

Standard tyres: 20.5 R25

Tipping load: 7500 kg

Wheel base: 2.975 m

Travel speed: 40 km/h

Steering mode: KL

Max. discharge height: 3.93 m

Turning radius outside: 6.11 m

Transport length: 6.53 m

Transport height: 3.25 m

Engine manuf.: DPS

Engine type: k.A.

Engine power: 123 kW

Displacement: 4.5 l

Max. torque: 682 Nm

No. of cylinders: 4

Emission level: IV

More technical details, like: operating weight, max. height at the shovel pivot point, overcharging height, turning radius inside, transport width, model series, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin: Yes
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Claas Torion 1511 FAQ

When was the Claas Torion 1511 manufactured?

The Claas Torion 1511 was manufactured from 2017 to 2020.

What is the weight of the Claas Torion 1511?

The Claas Torion 1511 has a weight of 14.06 tonnes.

What are the physical dimensions of the Claas Torion 1511?

The Claas Torion 1511 has a transport length of 6.53 meters and a transport height of 3.25 meters.

What is the travel speed of the Claas Torion 1511?

The Claas Torion 1511 has a travel speed of 40 km/h.

What are the maneuverability specifications of the Claas Torion 1511?

The Claas Torion 1511 features articulated-frame steering and has an outside turning radius of 6.11 meters.

What are the tyre specifications for the Claas Torion 1511?

The Claas Torion 1511 is equipped with standard tyres sized 20.5 R25.

What is the wheelbase of the Claas Torion 1511 yard loader?

The Claas Torion 1511 has a wheelbase of 2.975 meters.

What is the mass capacity of the Claas Torion 1511?

The Claas Torion 1511 has a tipping load of 7500 kilograms.

What is the maximum discharge height of the Claas Torion 1511?

The Claas Torion 1511 has a maximum discharge height of 3.93 meters.

How much is a Claas Torion 1511 Yard loader (2017u20132020) worth?

The residual value of the Claas Torion 1511 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
