Krypton M 105 SAME Krypton M 105 Specifications & Technical Data (2020—2024)

Engine power: 75kW – Model series: Krypton – Track width: 450mm – Transport length: 3.55m – Transport width: 1.8m – Transport height: 2.39m

Krypton M 105

Years of manufacture: 2020—2024

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Krypton M 105 SAME

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power: 75 kW

Model series: Krypton

Track width: 450 mm

Transport length: 3.55 m

Transport width: 1.8 m

Transport height: 2.39 m

Travel speed: 12.5 km/h

Transmission: 16/16

Transmission type: LS

Weight: 5.08 t

Control unit: 3 ew/dw

Engine manuf.: SDF

Engine type: FARMotion

Displacement: 3.849 l

Revolutions at max torque: 2200 rpm

No. of cylinders: 4

Emission level: III B (Tier 4 i)

More technical details, like: length of travelling mechanism, three point category, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin: No
Front hydraulics: No
Front PTO: No
Air brakes: No
ISO Bus: No
Aircondition: No

Download datasheets (PDF)

SAME Krypton M 105 FAQ

When did production of the SAME Krypton M 105 start?

The SAME Krypton M 105 was first produced in 2020.

What is the weight of the SAME Krypton M 105?

The SAME Krypton M 105 weighs 5.08 tonnes.

What are the physical dimensions of the SAME Krypton M 105 track tractor?

The SAME Krypton M 105 has a transport length of 3.55 meters, a transport width of 1.8 meters, and a transport height of 2.39 meters.

What is the engine power of the SAME Krypton M 105?

The SAME Krypton M 105 has an engine power of 75 kW.

What is the travel speed of the SAME Krypton M 105?

The SAME Krypton M 105 has a travel speed of 12.5 km/h.

What are the drivetrain and transmission specifications of the SAME Krypton M 105?

The SAME Krypton M 105 has a powershift transmission with 16 forward speeds and 16 reverse speeds.

What is the track width of the SAME Krypton M 105?

The SAME Krypton M 105 has a track width of 450 mm.

How much is a SAME Krypton M 105 Track tractor (2020u20132025) worth?

The residual value of the SAME Krypton M 105 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
