85D Challenger 85D Specifications & Technical Data (1996—1997)

Engine power: 275.9kW – Model series: 80D – Track width: 880mm – Transport length: 5.89m – Transport width: 3.04m – Transport height: 3.25m

Track tractors Challenger 85D

Technical specs - 85D Challenger

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
275.9 kW
Model series
80D
Track width
880 mm
Transport length
5.89 m
Transport width
3.04 m
Transport height
3.25 m
Transmission
10/2
Transmission type
LS
Weight
15.528 t
Engine manuf.
Caterpillar
Engine type
3196 ATAAC
Displacement
11.9 l
No. of cylinders
6
Cylinder bore x stroke
130x150 mm

More technical details, like: length of travelling mechanism, travel speed, control unit, three point category, dimension lxwxh, revolutions at max torque, max. torque, emission level are available in the full technical specs.

Special equipment

Cabin
Yes
Front hydraulics
No
Front PTO
No
Air brakes
No
ISO Bus
No
Aircondition
No

Challenger 85D FAQ

When was the Challenger 85D manufactured and what model series does it belong to?

The Challenger 85D was manufactured from 1996 to 1997 and belongs to the 80D model series.

What is the weight of the Challenger 85D track tractor?

The Challenger 85D track tractor weighs 15.528 tonnes.

What are the physical dimensions of the Challenger 85D track tractor?

The Challenger 85D has a transport length of 5.89 meters, a transport width of 3.04 meters, and a transport height of 3.25 meters.

What is the engine power of the Challenger 85D?

The Challenger 85D has an engine power of 275.9 kW.

What type of transmission does the Challenger 85D have?

The Challenger 85D is equipped with a Powershift transmission.

What is the track width of the Challenger 85D?

The Challenger 85D has a track width of 880 millimeters.

How much is a Challenger 85D Track tractor (1996u20131997) worth?

The residual value of the Challenger 85D depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
