Maxima 3 TIM L-E Kuhn Maxima 3 TIM L-E Specifications & Technical Data (2018—2023)

Working width: 6.4m – Transport width: 3.3m – Ø pressure roller: 500mm – Distance between rows: 650mm – No. of Plowshares: 9 – Type of Plowshares: 1-Sch.

Maxima 3 TIM L-E

Years of manufacture: 2018—2023

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Maxima 3 TIM L-E Kuhn

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Working width: 6.4 m

Transport width: 3.3 m

Ø pressure roller: 500 mm

Distance between rows: 650 mm

No. of Plowshares: 9

Type of Plowshares: 1-Sch.

Tank capacity: 50 l

No. of pressure rollers: 9

Attachment: D

More technical details, like: transport length, transport height, required power, weight are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Revolutions control: No
Pack Ring Roller: No
Drill manager: No
Row marker: No

Download datasheets (PDF)

Kuhn Maxima 3 TIM L-E FAQ

When was the Kuhn Maxima 3 TIM L-E manufactured?

The Kuhn Maxima 3 TIM L-E was manufactured from 2018 to 2023.

What is the transport width of the Kuhn Maxima 3 TIM L-E?

The Kuhn Maxima 3 TIM L-E has a transport width of 3.3 meters.

What is the working width of the Kuhn Maxima 3 TIM L-E sowing machine?

The Kuhn Maxima 3 TIM L-E has a working width of 6.4 meters.

What is the tank capacity of the Kuhn Maxima 3 TIM L-E?

The Kuhn Maxima 3 TIM L-E has a tank capacity of 50 liters.

What type of implement hitching does the Kuhn Maxima 3 TIM L-E use?

The Kuhn Maxima 3 TIM L-E uses a 3-point / double attachment for implement hitching.

What is the row spacing of the Kuhn Maxima 3 TIM L-E sowing machine?

The Kuhn Maxima 3 TIM L-E has a row spacing of 650 millimeters.

What are the sowing and planting components of the Kuhn Maxima 3 TIM L-E?

The Kuhn Maxima 3 TIM L-E features 9 one-disc coulter plowshares, 9 pressure rollers, each with a diameter of 500 mm.

How much is a Kuhn Maxima 3 TIM L-E Sowing machine (2018u20132023) worth?

The residual value of the Kuhn Maxima 3 TIM L-E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
