BOXER 2000 H Kuhn BOXER 2000 H Specifications & Technical Data (2023—2026)
.jpg)
.jpg)
Technical specs - BOXER 2000 H Kuhn
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 7.096 t
- Pump type
- Centrifugal
- Standard tyres
- 12.4 x 36 - optional 320/85 R36
- No. of partial widths
- 7
- Working width
- 27 m
- Travel speed
- 29 km/h
- Drive
- A
- Barrel volume
- 2000 l
- Pump capacity
- 220 l/min
- Transport length
- 7 m
- Transport width
- 3.2 m
- Transport height
- 3.87 m
- Model series
- Boxer
- Engine manuf.
- MWM
- Engine type
- 4.12 TCE
- Engine power
- 139.7 kW
- Displacement
- 4.8 l
More technical details, like: linkage type, foldable linkage, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
is a 0 for the size specification so that means, that no information is available.
Special equipment
- Hydr. Hillside /slope control
-
No
Download datasheets (PDF)
Kuhn BOXER 2000 H FAQ
What is the weight of the Kuhn BOXER 2000 H?
What are the transport dimensions of the Kuhn BOXER 2000 H?
What is the travel speed of the Kuhn BOXER 2000 H?
What type of drivetrain does the Kuhn BOXER 2000 H have?
What are the wheel and tyre specifications of the Kuhn BOXER 2000 H?
What is the primary working width of the Kuhn BOXER 2000 H?
What is the volume capacity of the Kuhn BOXER 2000 H?
How many partial widths does the Kuhn BOXER 2000 H's spraying system have?
What are the spraying and pump system specifications of the Kuhn BOXER 2000 H?
How much is a Kuhn BOXER 2000 H Self-propelled field sprayer (2023u20132025) worth?
