    SAME Dorado 90 LD Specifications & Technical Data (2019-2021)

    Rate this machine now!

    Engine power: 65kW – Back tyres: 480/70 R30 – Front tyres: 7.50-18 – Transport length: 3.997m – Transport width: 2.19m – Transport height: 2.59m

    Technical specs - Dorado 90 LD SAME

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    Engine power 65 kW
    Back tyres 480/70 R30
    Front tyres 7.50-18
    Transport length 3.997 m
    Transport width 2.19 m
    Transport height 2.59 m
    Travel speed 30 km/h
    Transmission 40/40
    Transmission type m
    Weight 3.2 t
    Control unit -/1 ew/dw
    Steering m
    Engine manuf. SDF
    Engine type FARMotion
    Engine power 88 HP
    Displacement 2.887 l
    Revolutions at max torque 2200 rpm
    No. of cylinders 3
    Emission level III B
    three point category ###
    Dimension lxwxh ###
    Max. torque ###
    Cylinder bore x stroke ###
    Weight ###

    is a 0 for the size specification so that means, that no information is available.

    Dorado 90 LD SAME - Special equipment

    • Cabin
    • Front hydraulics
    • Front PTO
    • Air brakes
    • ISO Bus
    • Aircondition
