Lectura specs Construction machinery Cold Milling Machines Cold Milling Machines Wirtgen Wirtgen W 100 R specifications

Cold Milling Machines Wirtgen W 100 R
Wirtgen

Wirtgen W 100 R Specifications & Technical Data (2016-2023)

Rate this machine now!

Weight: 14t – Standard tyres: 620x230 / 620x255 – Cutting width: 1000mm – Cutting depth: 300mm – Operating speed: 33m/min – Travel speed : 7.5km/h

Technical specs - W 100 R Wirtgen

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Weight 14 t
  • Standard tyres 620x230 / 620x255
  • Cutting width 1000 mm
  • Cutting depth 300 mm
  • Operating speed 33 m/min
  • Travel speed 7.5 km/h
  • Transport length 4.75 m
  • Transport width 2.29 m
  • Transport height 3.67 m
  • Model series Small milling machines
  • Engine manuf. Deutz
  • Engine type TCD2012 L06 2V
  • Engine power 155 kW
  • Displacement 6.057 l
  • Revolutions at max torque 2300 rpm
  • Emission level Euro III a/US Tier 3

More technical details, like: average fuel consumption, fuel consumption range (min - max), track width, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with cutting tools

Special equipment

  • Diesel particulate filter
  • Cabin
  • Front loading conveyor
  • Infrared heater
  • Aircondition
