Wacker BS 500 Oi Specifications & Technical Data (2003-2004)

Rate this machine now!

Weight: 52kg – Tamper amplitude: 60mm – Tamper width: 280mm – Single stroke energy: 60J – max. No. of strokes: 7501/min – Power source: gasoline

Technical specs - BS 500 Oi Wacker

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Weight 52 kg
  • Tamper amplitude 60 mm
  • Tamper width 280 mm
  • Single stroke energy 60 J
  • max. No. of strokes 750 1/min
  • Power source gasoline
  • Model series BS
  • Engine manuf. Wacker
  • Engine type WM 80
  • Engine power 1.1 kW
  • Displacement 0.08 l
  • Revolutions at max torque 4400 rpm

More technical details, like: dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Special equipment

  • Tamper width variable
  • driving device

Carbon footprint calculator for Gasoline and Diesel Rammers

See the ERA equipment CO2 Calculator to find out the carbon emissions per hour of use of the Wacker BS 500 Oi or alternative Gasoline and Diesel Rammers.

The emission evaluation can be carried out based on different motor oil consumption scenarios or other variables.

or visit the ERA Equipment CO2 Calculator to find out how to optimise your carbon footprint.

service provided by ERA

Buy & Rent

Compare Wacker BS 500 Oi with similar Gasoline and Diesel Rammers

Press 1 image

Wacker BS 500 Oi

Weight: 52 kg

Tamper amplitude: 60 mm

Tamper width: 280 mm

Single stroke energy: 60 J

Press 1 image
Wacker Neuson BS 50-4 As 11"

Weight: 62 kg

Tamper amplitude: 55 mm

Tamper width: 280 mm

Single stroke energy: 75 J

Press 1 image
Bomag BT 50

Weight: 54 kg

Tamper amplitude: 60 mm

Tamper width: 230 mm

Single stroke energy: 75 J

Press 1 image
Dynapac LT 52

Weight: 55 kg

Tamper amplitude: 40 mm

Tamper width: 250 mm

Press 1 image
PowerPac PPS 50 H

Weight: 50.5 kg

Tamper amplitude: 66 mm

Tamper width: 190 mm
