INMESOL IK-033 Specifications & Technical Data (2018-2023)

Rate this machine now!

Nominal output: 31.9KVA – Nominal voltage: 400V – Weight: 970kg – Type of cooling: l – Transport length: 2m – Transport width: 0.95m

Technical specs - IK-033 INMESOL


Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Nominal output 31.9 KVA
  • Nominal voltage 400 V
  • Weight 970 kg
  • Type of cooling l
  • Transport length 2 m
  • Transport width 0.95 m
  • Transport height 1.253 m
  • Model series IK
  • Engine manuf. Kohler
  • Engine type KDI2504TM30
  • Engine power 28.2 kW
  • Displacement 2.482 l
  • No. of cylinders 4
  • Cylinder bore x stroke 88x102 mm

More technical details, like: average fuel consumption, fuel consumption range (min - max), nominal current, carriage, dimension lxwxh, revolutions at max torque, max. torque, emission level are available in the full technical specs.

Basic model

Special equipment

  • Electric starter
  • silenced
  • Earth leakage monitor
  • Automatic oil deficiency shutoff
  • Thermo magnetic switch
  • Ground fault circuit interrupter
