Atlas Copco QES 14
- Nominal output:
- 13.8 KVA
- Nominal current:
- 19.9 A
- Weight:
- 680 kg
- Type of cooling:
- w
Atlas Copco QES 14 Specifications & Technical Data (2020-2025)
.jpeg)
Technical specs - QES 14 Atlas Copco
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Nominal output
- 13.8 KVA
- Nominal current
- 19.9 A
- Weight
- 680 kg
- Type of cooling
- w
- Carriage
- F
- Transport length
- 1.75 m
- Transport width
- 0.84 m
- Transport height
- 1.12 m
- Model series
- QES
- Engine manuf.
- Kubota
- Engine type
- D1705M-E4BG
- Engine power
- 13.2 kW
- Displacement
- 1.7 l
- Revolutions at max torque
- 1500 rpm
- No. of cylinders
- 3
- Emission level
- V
More technical details, like: nominal voltage, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model
Special equipment
- Electric starter
-
No
- silenced
-
No
- Earth leakage monitor
-
No
- Automatic oil deficiency shutoff
-
No
- Thermo magnetic switch
-
No
- Ground fault circuit interrupter
-
No
