Atlas Copco QAS 14 KD
- Nominal output:
- 14.1 KVA
- Nominal current:
- 20.4 A
- Nominal voltage:
- 400 V
- Weight:
- 1010 kg
Atlas Copco QAS 14 KD Specifications & Technical Data (2020-2025)
.jpeg)
Technical specs - QAS 14 KD Atlas Copco
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Nominal output
- 14.1 KVA
- Nominal current
- 20.4 A
- Nominal voltage
- 400 V
- Weight
- 1010 kg
- Type of cooling
- w
- Carriage
- F
- Transport length
- 2.39 m
- Transport width
- 1.41 m
- Transport height
- 1.7 m
- Model series
- QAS
- Engine manuf.
- Kubota
- Engine type
- D1705M-E4BG
- Engine power
- 13.2 kW
- Displacement
- 1.7 l
- Revolutions at max torque
- 1500 rpm
- No. of cylinders
- 3
- Emission level
- V
More technical details, like: dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model
Special equipment
- Electric starter
-
Yes
- silenced
-
Yes
- Earth leakage monitor
-
No
- Automatic oil deficiency shutoff
-
No
- Thermo magnetic switch
-
No
- Ground fault circuit interrupter
-
No
Download datasheets (PDF)
