Atlas Copco XAVS 448 SD Specifications & Technical Data (2020-2025)

Volume flow: 26.4m³/min – Engine power: 232kW – Max. pressure: 14bar – Weight: 5641kg – Transport length: 4.05m – Transport width: 2.14m

Technical specs - XAVS 448 SD Atlas Copco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Volume flow
26.4 m³/min
Engine power
232 kW
Max. pressure
14 bar
Weight
5641 kg
Transport length
4.05 m
Transport width
2.14 m
Transport height
2.23 m
Model series
XAVS
Engine manuf.
Scania
Engine type
DC 9
Displacement
9.3 l
Revolutions at max torque
1800 rpm
Emission level
V

More technical details, like: voltage, frequency, power source, additional power set, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Download datasheets (PDF)

Buy & Rent

Compare Atlas Copco XAVS 448 SD with similar Stationary Air Compressors - Diesel, Electric, Gasoline

Atlas Copco XAVS 448 SD

Atlas Copco XAVS 448 SD

Volume flow:
26.4 m³/min
Engine power:
232 kW
Max. pressure:
14 bar
Weight:
5641 kg
Kaeser Mobilair M 250

Kaeser Mobilair M 250

Volume flow:
25.5 m³/min
Engine power:
215 kW
Max. pressure:
8.6 bar
Weight:
3900 kg
Doosan XHP900WCAT

Doosan XHP900WCAT

Volume flow:
25.5 m³/min
Engine power:
298 kW
Max. pressure:
24.1 bar
Weight:
5761 kg
