Atlas Copco XATS 288 Jd DPF Specifications & Technical Data (2020-2020)

Volume flow: 11.4m³/min – Max. pressure: 10bar – Weight: 2650kg – Power source: Diesel – Transport length: 4.945m – Transport width: 1.81m

Technical specs - XATS 288 Jd DPF Atlas Copco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Volume flow
11.4 m³/min
Max. pressure
10 bar
Weight
2650 kg
Power source
Diesel
Transport length
4.945 m
Transport width
1.81 m
Transport height
1.835 m
Engine power
117 kW
Model series
XATS
Engine manuf.
John Deere
Engine type
4045HFC09
Revolutions at max torque
2150 rpm
Emission level
V

More technical details, like: additional power set, voltage, frequency, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
