Atlas Copco XAS 238-14 Jd DPF Specifications & Technical Data (2021-2025)
.jpg)
Technical specs - XAS 238-14 Jd DPF Atlas Copco
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Volume flow
- 14.82 m³/min
- Max. pressure
- 14 bar
- Weight
- 2650 kg
- Power source
- Diesel
- Transport length
- 4.95 m
- Transport width
- 1.81 m
- Transport height
- 1.94 m
- Engine power
- 117 kW
- Model series
- XAS
- Engine manuf.
- John Deere
- Engine type
- 4045CA550
- Revolutions at max torque
- 2150 rpm
- Emission level
- V
More technical details, like: additional power set, voltage, frequency, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
