Atlas Copco E-Air H250 VSD Specifications & Technical Data (2020-2025)

Volume flow: 7m³/min – Max. pressure: 12bar – Weight: 700kg – Power source: electric – Transport length: 1.94m – Transport width: 1.16m

Technical specs - E-Air H250 VSD Atlas Copco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Volume flow
7 m³/min
Max. pressure
12 bar
Weight
700 kg
Power source
electric
Transport length
1.94 m
Transport width
1.16 m
Transport height
1.31 m
Engine power
37 kW
Voltage
530 V
Frequency
60 Hz
Model series
E-Air
Engine manuf.
k.A.
Engine type
Elektro

More technical details, like: additional power set, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Download datasheets (PDF)
