    John Deere 3039 R Specifications & Technical Data (2020-2023)

    Rate this machine now!

    Weight without attachment: 1.7t – Transport length: 3.23m – Transport width: 1.728m – Transport height: 2.37m – Standard tyres: VR 27x8.50-15 HR 41x14-20 – Attachment: H/M/F

    Technical specs - 3039 R John Deere


    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Weight without attachment 1.7 t
    • Transport length 3.23 m
    • Transport width 1.728 m
    • Transport height 2.37 m
    • Standard tyres VR 27x8.50-15 HR 41x14-20
    • Attachment H/M/F
    • Travel speed 30 km/h
    • Steering mode FL
    • Engine manuf. John Deere
    • Engine type k.A.
    • Engine power 28.5 kW
    • Displacement 1.6 l
    • Revolutions at max torque 2600 rpm
    • Max. torque 127 Nm
    • No. of cylinders 3

    More technical details, like: bridge length, bridge width, transmission, dimension lxwxh, cylinder bore x stroke, weight, emission level are available in the full technical specs.

    Basic model with cabin, platform (standard dimensions), front wheel steering and normal tyres

    Special equipment

    • Cabin
    • Front hydraulics
    • All-wheel drive
    • Codriver seat
    • Rear hydraulic
    • Frontblade
    • Narrow-gauge
    • Load tippable
    • Power take-off
