Kubota B1181 DST Specifications & Technical Data (2017-2022)

Name: Kubota B1181 DST Compact Utility Tractors
Brand: Kubota

Weight without attachment: 0.649t – Travel speed: 20km/h – Back tyres: 280/70R19 – Front tyres: 23x10.50-13 – Transport length: 2.45m – Transport width: 1.15m

Vehicles Compact Utility Tractors Kubota B1181 DST

B1181 DST

Years of manufacture: 2017—2022

Data sheet
Buy & Rent
Spare parts
Transport
Events & News

Technical specs - B1181 DST Kubota

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight without attachment: 0.649 t

Travel speed: 20 km/h

Back tyres: 280/70R19

Front tyres: 23x10.50-13

Transport length: 2.45 m

Transport width: 1.15 m

Transport height: 2.45 m

Transmission: 6/5

Attachment: H/M/F

Model series: B

Engine manuf.: Kubota

Engine type: D782

Engine power: 12 kW

Displacement: 0.778 l

No. of cylinders: 3

Emission level: V

More technical details, like: bridge length, bridge width, steering mode, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, weight are available in the full technical specs.

Special equipment

Cabin: No
Front hydraulics: Yes
Front PTO: Yes
All-wheel drive: Yes
Codriver seat: No
Rear hydraulic: Yes
Frontblade: No
Load tippable: No
Rear PTO: Yes
