Caterpillar NSS16N2 Sit down rider pallet stacker specs (2024 - 2024)

Name: Caterpillar NSS16N2 Pallet Stackers Sit Down Rider
Brand: Caterpillar

Nominal load at COG: 1.6t – Wheel base: 1.616m – Standard tyres: Drive: 250 x 105 / Load: 85 x 70 – Transport length: 2.189m – Tra…

Nominal load at COG: 1.6t – Wheel base: 1.616m – Standard tyres: Drive: 250 x 105 / Load: 85 x 70 – Transport length: 2.189m – Transport width: 1.01m – Centre of gravity: 600mm

NSS16N2 Sit down rider pallet stacker model manufactured by Caterpillar in (2024 - 2024). Explore detailed NSS16N2 Sit down rider pallet stacker specs: technical details, table charts and data sheets to download. Check also the other pallet stacker and straddle stacker models produced by Caterpillar.

Pallet Stackers Pallet Stackers Sit Down Rider Caterpillar NSS16N2

Technical specs - NSS16N2 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 1.6 t

Wheel base: 1.616 m

Standard tyres: Drive: 250 x 105 / Load: 85 x 70

Transport length: 2.189 m

Transport width: 1.01 m

Centre of gravity: 600 mm

Traction motor: 2.7 kW

Hoist motor: 4 kW

Battery capacity: 24/775 V/Ah

Weight: 1.866 t

Battery weight: 0.62 t

Travel speed with / without load: 10/10 km/h

Hoisting with / without load: 0.16/0.32 m/s

Lowering with load: 0.44 m/s

max. climbing ability: 6.7 %

Turning radius: 1.819 m

Model series: NSS

More technical details, like: transport height, lifting height are available in the full technical specs.

Special equipment

Double lift: No
Initial lift: Yes
Scissor lift: No
