Zeppelin ZBK 100-FKF46-TS13-SL crane - load chart, specs & dimensions (1992 - 1998)

Name: Zeppelin ZBK 100-FKF46-TS13-SL Tower Cranes - Trolley Boom - Top-slewing
Brand: Zeppelin

Manufactured by Zeppelin, this is the ZBK 100-FKF46-TS13-SL tower crane - trolley boom - top-slewing. Find and download detailed s…

Manufactured by Zeppelin, this is the ZBK 100-FKF46-TS13-SL tower crane - trolley boom - top-slewing. Find and download detailed specs and data sheets for this machine here.

The Zeppelin ZBK 100-FKF46-TS13-SL can be grouped in the smallest machine segment in the tower crane - trolley boom - top-slewing category. The max. Standard boom of this Zeppelin model is 40m. 6t is the maximum carrying capacity of this Zeppelin ZBK 100-FKF46-TS13-SL crane, according to its specification. The Zeppelin ZBK 100-FKF46-TS13-SL crane provides 19.2m reach while carrying the maximum load. The datasheet for ZBK 100-FKF46-TS13-SL indicates that this model can carry a 2.5t load at max. Reach. As stated in model specifications, the nominal torque is 1134. The max. Hook height is 36.4m.

The Zeppelin ZBK 100-FKF46-TS13-SL has been equipped and sold with Cross girder, Add. Ballast and Cabin. Climbing device and Undercarriage are not provided on this model as of 1998. Get the original Zeppelin ZBK 100-FKF46-TS13-SL datasheet for even more detailed specifications and machine details.

The production in 1998, where this ZBK 100-FKF46-TS13-SL was available at a new list price between €234,000 and €297,000.

Comparisons of the ZBK 100-FKF46-TS13-SL Zeppelin with other tower cranes - trolley boom - top-slewing models reveal that, based on specifications and pricing, the model is similar to the Potain MD 120, Potain MDT 120-G6 as well as ITK ITK 6612-8. Want more detailed specifications? Download the latest Zeppelin ZBK 100-FKF46-TS13-SL specs data sheet on LECTURA Specs today!

ZBK 100-FKF46-TS13-SL

Years of manufacture: 1992—1998

Buy & Rent
Spare parts
Transport
Events & News

Technical specs - ZBK 100-FKF46-TS13-SL Zeppelin

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal torque: 1134 kNm

Max. load: 6 t

Load at max. Reach: 2.5 t

Reach at max. Load: 19.2 m

max. standard boom: 40 m

max. hook height: 36.4 m

Connection load: 40 KVA

Model series: ZBK

More technical details, like: ropes, max. reach, max. luffing jib, min. luffing jib, tower height, max. hoisting speed, tower system, drive system, hoist unit are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

Cabin: Yes
Add. ballast: Yes
Rail carrier: Yes
Climbing device: No
Undercarriage: No
Cross girder: Yes
