Terex Comedil (Zeppelin) CTT 721B-40 crane - load chart, specs (2020 - 2024)

Name: Terex Comedil (Zeppelin) CTT 721B-40 Tower Cranes - Trolley Boom - Top-slewing
Brand: Terex Comedil (Zeppelin)

Nominal torque: 8730kNm – Max. load: 40t – max. reach: 85m – Load at max. Reach: 3.95t – Reach at max. Load: 15.83m – max. standar…

Nominal torque: 8730kNm – Max. load: 40t – max. reach: 85m – Load at max. Reach: 3.95t – Reach at max. Load: 15.83m – max. standard boom: 85m

See load chart, specs, capacity, size and other technical data for Terex Comedil (Zeppelin) CTT 721B-40 crane manufactured between 2020 - 2024. See information, like: Nominal torque: 8730kNm – Max. load: 40t – max. reach: 85m – Load at max. Reach: 3.95t – Reach at max. Load: 15.83m – max. standard boom: 85m and more.

Tower Cranes - Trolley Boom - Top-slewing Terex Comedil (Zeppelin) CTT 721B-40

Technical specs - CTT 721B-40 Terex Comedil (Zeppelin)

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal torque: 8730 kNm

Max. load: 40 t

max. reach: 85 m

Load at max. Reach: 3.95 t

Reach at max. Load: 15.83 m

max. standard boom: 85 m

max. hook height: 71.1 m

Ropes: 4

Tower system: HD 23

Drive system: 94 AFC 200 D3

Connection load: 200 KVA

Model series: CTT

More technical details, like: max. luffing jib, min. luffing jib, tower height, max. hoisting speed, hoist unit are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

Cabin: Yes
Add. ballast: Yes
Rail carrier: No
Climbing device: No
Undercarriage: Yes
Cross girder: No
