Terex Comedil (Zeppelin) CTL 140-10 crane - load chart, specs (2006 - 2019)

Rate this machine now!

Nominal torque: 1830kNm – Max. load: 5t – max. reach: 50m – Load at max. Reach: 1.7t – Reach at max. Load: 26.61m – max. standard ... Read more

Nominal torque: 1830kNm – Max. load: 5t – max. reach: 50m – Load at max. Reach: 1.7t – Reach at max. Load: 26.61m – max. standard boom: 50m

See load chart, specs, capacity, size and other technical data for Terex Comedil (Zeppelin) CTL 140-10 crane manufactured between 2006 - 2019. See information, like: Nominal torque: 1830kNm – Max. load: 5t – max. reach: 50m – Load at max. Reach: 1.7t – Reach at max. Load: 26.61m – max. standard boom: 50m and more.

Technical specs - CTL 140-10 Terex Comedil (Zeppelin)

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Nominal torque 1830 kNm
  • Max. load 5 t
  • max. reach 50 m
  • Load at max. Reach 1.7 t
  • Reach at max. Load 26.61 m
  • max. standard boom 50 m
  • max. hook height 86.55 m
  • Ropes 2/3/4
  • Tower system TS 16
  • Drive system 43 AFC 50
  • Connection load 104 KVA

More technical details, like: max. luffing jib, min. luffing jib, tower height, max. hoisting speed, hoist unit, model series are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

  • Cabin
  • Add. ballast
  • Rail carrier
  • Climbing device
  • Undercarriage
  • Cross girder
