    Lectura specs Cranes Tower Cranes - Trolley Boom - Top-slewing Tower Cranes - Trolley Boom - Top-slewing Potain Potain MDT 412 (L12) specifications

    Potain MDT 412 (L12) crane - load chart, specs (2002 - 2003)

    Rate this machine now!

    Manufactured by Potain, this is the MDT 412 (L12) tower crane - trolley boom - top-slewing. Find and download detailed specs and d... Read more

    Manufactured by Potain, this is the MDT 412 (L12) tower crane - trolley boom - top-slewing. Find and download detailed specs and data sheets for this machine here.

    The Potain MDT 412 (L12) can be grouped in the biggest machine segment in the tower crane - trolley boom - top-slewing category. 75m is the maximum length of the standard boom for the MDT 412 (L12) crane. The carrying capacity of this Tower crane - Trolley boom - top-slewing is 20t. 15.2m is the reach of MDT 412 (L12) when lifting the maximum load. The MDT 412 (L12) is able to lift a load weighing 2.7t at its maximum reach. As stated in model specifications, the nominal torque is 4120. The load can be lifted by the hook to 42.9m height.

    Since 2002, this model has included Cabin and Add. Ballast. It does not include Rail carrier, Undercarriage and Climbing device. More detailed specifications and machine descriptions can be found in the original Potain MDT 412 (L12) specs data sheet.

    The newest version of this MDT 412 (L12) model is priced between €794,000 and €1,010,000, with the production of this model in 2003.

    The MDT 412 (L12) Potain can be compared to several models from other manufacturers. The closest tower cranes - trolley boom - top-slewing based on specification and pricing are the Wilbert WT 420 e.Tronic, Wilbert WT 420 e.Tronic and Terex Comedil (Zeppelin) CTT 361-20. Want more detailed specifications? Download the latest Potain MDT 412 (L12) specs data sheet on LECTURA Specs today!

    Technical specs - MDT 412 (L12) Potain

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Nominal torque 4120 kNm
    • Max. load 20 t
    • Load at max. Reach 2.7 t
    • Reach at max. Load 15.2 m
    • max. standard boom 75 m
    • max. hook height 42.9 m
    • Ropes ###
    • Connection load 110 KVA
    • max. reach ###
    • Max. luffing jib ###
    • min. luffing jib ###
    • Tower height ###
    • max. hoisting speed ###
    • Tower system ###
    • Drive system ###
    • Hoist unit ###

    If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

    Special equipment

    • Cabin
    • Add. ballast
    • Rail carrier
    • Climbing device
    • Undercarriage
    • Cross girder
