Liebherr 200 EC-B 10 Litronic crane - load chart, specs (2007 - 2017)
Manufactured by Liebherr, this is the 200 EC-B 10 Litronic tower crane - trolley boom - top-slewing. Find and download detailed sp... Read more
Manufactured by Liebherr, this is the 200 EC-B 10 Litronic tower crane - trolley boom - top-slewing. Find and download detailed specs and data sheets for this machine here.
The Liebherr 200 EC-B 10 Litronic can be grouped in the medium sized machine segment in the tower crane - trolley boom - top-slewing category. 45m is the maximum length of the standard boom for the 200 EC-B 10 Litronic crane. The 200 EC-B 10 Litronic Tower crane - Trolley boom - top-slewing has a maximum capacity of 12t. 22.2m is the reach of 200 EC-B 10 Litronic when lifting the maximum load. The 200 EC-B 10 Litronic is able to lift a load weighing 4.45t at its maximum reach. The rate of nominal torque is 2000. The max. Hook height is 60m.
The Liebherr 200 EC-B 10 Litronic has been equipped and sold with Cabin and Undercarriage. It does not include Add. Ballast, Cross girder and Rail carrier. More detailed specifications and machine descriptions can be found in the original Liebherr 200 EC-B 10 Litronic specs data sheet. You can download it for free in French, Italian, German, Spanish and English on LECTURA Specs.
The production in 2017, where this 200 EC-B 10 Litronic was available at a new list price between €504,000 and €641,000.
Comparisons of the 200 EC-B 10 Litronic Liebherr with other tower cranes - trolley boom - top-slewing models reveal that, based on specifications and pricing, the model is similar to the Wolff 6522 FL 6/12, Wilbert WT 200 e.Tronic as well as Wolff 6522 FL 6. Want more detailed specifications? Download the latest Liebherr 200 EC-B 10 Litronic specs data sheet on LECTURA Specs today!
Technical specs - 200 EC-B 10 Litronic Liebherr
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.
- Nominal torque 2000 kNm
- Max. load 12 t
- max. reach 45 m
- Load at max. Reach 4.45 t
- Reach at max. Load 22.2 m
- max. standard boom 45 m
- max. hook height 60 m
- Tower system 185 HC
- Connection load 63 KVA
- Model series 200
More technical details, like: max. luffing jib, min. luffing jib, tower height, ropes, max. hoisting speed, drive system, hoist unit are available in the full technical specs.
If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)
Special equipment
- Cabin
- Add. ballast
- Rail carrier
- Climbing device
- Undercarriage
- Cross girder
