    Vögele Super 1803-3i Specifications & Technical Data (2021-2022)

    Rate this machine now!

    Transport length: 6.04m – Transport width: 3m – Transport height: 3.1m – Standard width: 3m – Max. width: 8m – Drive: DM

    Technical specs - Super 1803-3i Vögele

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Transport length 6.04 m
    • Transport width 3 m
    • Transport height 3.1 m
    • Standard width 3 m
    • Max. width 8 m
    • Drive DM
    • Wheels 6x4
    • Operating speed 18 m/min
    • Type of screed V/T
    • Engine manuf. Cummins
    • Engine type B6.7-C173
    • Engine power 129 kW
    • Displacement 6.7 l
    • No. of cylinders 6
    • Emission level EU Stage V, US EPA Tier 4f

    More technical details, like: weight, hydr. extension from, hydr. extension up to, bunker capacity, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

    Basic model with operator cabin roof, std. beam and screed plate heating Prices and weights refer to the std. width (most demanded/sold width), excl. hydraulic or manual extention

    Special equipment

    • Diesel particulate filter
    • Bilateral levelling automatic
    • Vibration
    • High compaction
    • Spray unit
    • Tamper
