Case 321F Specifications & Technical Data (2021-2024)

Rate this machine now!

The Case 321F is a wheel loader manufactured by Case since 2021. It has a weight of 6.53 tons and a transport length of 5.68 meter... Read more

The Case 321F is a wheel loader manufactured by Case since 2021. It has a weight of 6.53 tons and a transport length of 5.68 meters. The bucket capacity is 1.2 cubic meters, with a bucket width of 2.1 meters. The maximum discharge height is 2.69 meters. It has a travel speed of 33 kilometers per hour. The transport width is 2.1 meters, and the transport height is 2.68 meters. The lifting force is 60.5 kilonewtons, and the turning radius outside is 3.99 meters. The minimum bucket capacity is also 1.2 cubic meters. It includes special equipment such as a quick hitch hydrant.

Technical specs - 321F Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Weight 6.53 t
  • Standard tyres 14.5-20
  • Bucket width 2.1 m
  • Bucket capacity 1.2 m³
  • Bucket capacity min. 1.2 m³
  • Steering mode KL
  • Transport length 5.68 m
  • Transport width 2.1 m
  • Transport height 2.68 m
  • Travel speed 33 km/h
  • Max. discharge height 2.69 m
  • Turning radius outside 3.99 m
  • Lifting force 60.5 kN
  • Model series F
  • Engine manuf. CNH
  • Engine type F5H
  • Engine power 55 kW
  • Displacement 3.4 l
  • Revolutions at max torque 2100 rpm
  • Max. torque 316 Nm
  • Emission level V

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

  • Diesel particulate filter
  • Swing loader
  • telescopic
  • Aircondition
  • Quick hitch hydr.
  • Quick hitch mech.
