Lectura specs Construction machinery Tracked Asphalt Pavers Tracked Asphalt Pavers Vögele Vögele SUPER 1880-3 L specifications

Vögele SUPER 1880-3 L Specifications & Technical Data (2021-2024)

Rate this machine now!

Transport length: 6.57m – Transport width: 3m – Transport height: 3.102m – Standard width: 3.261m – Max. width: 9.5m – Drive: DM

Technical specs - SUPER 1880-3 L Vögele


Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Transport length 6.57 m
  • Transport width 3 m
  • Transport height 3.102 m
  • Standard width 3.261 m
  • Max. width 9.5 m
  • Drive DM
  • Operating speed 24 m/min
  • Type of screed V/T
  • Engine manuf. Cummins
  • Engine type QSB6.7-C215
  • Engine power 158 kW
  • Displacement 6.7 l
  • No. of cylinders 6
  • Emission level Stage III (MEP)

More technical details, like: weight, hydr. extension from, hydr. extension up to, soil pressure, bunker capacity, model series, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with operator cabin roof, std. beam and screed plate heating Prices and weights refer to the std. width (most demanded/sold width), excl. hydraulic or manual extention

Special equipment

  • Diesel particulate filter
  • Bilateral levelling automatic
  • Vibration
  • High compaction
  • Spray unit
  • Tamper
